Description
Description:
Other ethernet 'modems' may use workarounds to get a public IP address through to your secondary device or client, requiring non standard operation and complicated dual stage setup (modem logs in, router routes) and yet the Vigor 167 provides the secondary device with a real routed IP connection and the ability to fully manage the connection, making setup easy i.e. just plug it in and set up your PC or router. All login/ISP details are entered on the connected client device, not the Vigor 167. The actual connection to your ISP is still PPPoA or PPPoE, depending on your ISP and line type.
This transparent bridging method also differs from using a normal ADSL/VDSL router which logs in itself and then uses NAT or multiple public IP addresses to create an onward client connection for your secondary device; that is not IP address thrifty and can introduce secondary NAT compromises or interference with various protocols/traffic. With the Vigor 167 you get a true single public IP address, or multiple, if you have them, straight through to your firewall/router.
Features:
- ADSL & VDSL (FTTC/BT Infinity) ethernet modem
- Ideal partner device for DrayTek dual WAN products
- Ethernet connection for client device (router, PC etc.)
- ADSL and VDSL parameters pre set for UK ISPs (adjustable)
- Normally no setup or configuration of the Vigor 167 required
- Bridge (pass) a single IP address or a whole public subnet
- IPv6 and IPv4 compatible
- PPPoA/PPPoE bridging compatible with ISPs running IPv6
- Ideal for customers wanting to use their own router rather than the one provided by their ISP
Specifications:
| Physical Interfaces | RJ-11 - ADSL/VDSL2 Line RJ-45 - Gigabit 10/100/1000BaseT Ethernet (auto-sensing/MDI-X) Power Socket (DC) |
| Features | Pre-Configured VDSL2/ADSL to Ethernet Bridging Modem Built-in Diagnostics (WUI / CLI) Support for MTU1508 (Jumbo Frames) Bridging mode IPTV (YouView, Sky Q) Relay IPv6 and IPv4 Compatible DSL Line Stat information relay to DrayTek Vigor routers |
| Protocol Support | ITU-T G.993.1 VDSL ITU-T G.993.2 VDSL2 ITU-T G.997.1 G.INP / G.998.4 VDSL Annex A, Annex C, Annex M VDSL Profiles: 8a, 8b, 8c, 8d, 12a, 12b, 17a VDSL2 Vectoring BT SIN 498 MCT Approved OLR, UPBO, DBPO, US0 ANSI T1.413 Issue 2 ITU-T G.992.1 G.dmt (ADSL) ITU-T G.992.3 ADSL2 ITU-T G.992.5 ADSL2+ ADSL Annex L (READSL) ADSL Annex M PPPoA-PPPoE or PPPoE-PPPoE Bridging (WAN to LAN) RFC-2684 / RFC-1483 |
| Environmental | Operating : 0°C to 45°C Storage : -25°C to 70°C Humidity : 20% to 90% Non condensing |
| Dimensions | Height: 40mm Width: 182mm Depth: 125mm |
| Power | 220-240VAC (to DC with supplied Plug-Top PSU) Power Adapter: DC 12V/1A Max. Power: 6 watt |
User guides
Download User Guides:
Data Sheet
DrayTek Data Book
Quick Start Guide
Security Best Practice White Paper
Declaration of Conformity
