Description
Description:
It offers high throughput with Load Balancing and Failover connectivity, suitable for handling Fibre to the Premises (FTTP) and Gigabit internet connections.
Offering up to 950Mbps per WAN of hardware accelerated throughput while retaining its full feature set.
Features:
- Gigabit dual WAN ethernet WAN router with load balancing and failover
- Up to 950Mbps throughput per WAN interface, 1800Mbps in total
- Up to 300Mbps IPsec VPN throughput
- 50 LAN to LAN and remote worker VPN tunnels
- 25 DrayTek SSL VPN tunnels
- 5+1 Gigabit RJ-45 LAN ports
- 8 LAN subnets with VLANs (port based / 802.1q)
- SPI Firewall and Content Filtering
- Optional VigorCare available
- Can be centrally managed by VigorACS
Specifications:
| Physical Interfaces | WAN Ports: 1x Gigabit Ethernet (1G/100M/10M), RJ-45 WAN/LAN Switchable Ports: 1x Gigabit Ethernet (1G/100M/10M), RJ-45 LAN Ports: 5x Gigabit Ethernet (1G/100M/10M), RJ-45 2x USB 2.0 Ports for 3G/4G Modem, thermometer or Printer Recessed Factory Reset button |
| Performance | NAT Performance: 950 Mb/s NAT Throughput for Single WAN with Hardware Acceleration 1.8Gb/s Total NAT Throughput for Dual WAN with Hardware Acceleration 800 Mb/s NAT Throughput per WAN 60,000 NAT Sessions 8000 Hardware Accelerated NAT Sessions |
| Internet Connection | Load Balancing: IP-based, Session-based Hardware Acceleration 802.1p/q Multi-VLAN Tagging Multi-VLAN/PVC WAN Active on Demand: Link Failure, Traffic Threshold Connection Detection: PPP, ARP Detect, Ping Detect WAN Data Budget Dynamic DNS DrayDDNS with automated LetsEncrypt Certificates Hardware Accelerated Quality of Service Multi-WAN Data Budget Traffic Graph & Data Flow Monitor Bandwidth Limit |
| Firewall & Content Filtering | IP-based or User-based Firewall Policy User-based Time Quota DoS Attack Defence Spoofing Defence Content Filtering: Application Content Filter URL Content Filter DNS Keyword Filter Web Features |
| LAN Management | 802.1q Tag-based, Port-based VLAN Up to 8 LAN Subnets (NAT or Routing mode selectable per LAN interface) Up to 16 VLANs Multiple IP Subnet Custom DHCP Options Bind-IP-to-MAC DHCP Pool Count up to 1022 addresses for LANs 1-3 DHCP Pool Count up to 253 addresses for LANs 4-8 Wired 802.1x Port Authentication Port Mirroring Local DNS Server Conditional DNS Forwarding Hotspot Web Portal Hotspot Authentication: Click-Through, Social Login, SMS PIN, Voucher PIN, RADIUS, External Portal Server |
| Networking Features | Policy-based Routing: Protocol, IP Address, Port, Domain/Hostname, Country High Availability: Active-Standby, Hot-Standby DNS Security (DNSSEC) Local RADIUS server SMB File Sharing (Requires external storage) Multicast: IGMP Proxy, IGMP Snooping & Fast Leave, Bonjour Routing Features: IPv4 & IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2/ng, BGP |
| Bandwidth Management | IP based Bandwidth Limit IP based Session Limit User based Data Quota |
| Quality of Service (QoS) | Classify via TOS, DSCP, 802.1p, IP Address, Service Type 4 Priority Queues App QoS VoIP Prioritisation Class-based Outbound Traffic Tagging: DSCP & IP Precedence |
| Management | Local Service: HTTP, HTTPS, Telnet, SSH, FTP, TR-069 Config File Export & Import Import Config from Vigor 2926 Auto Backup Config to USB Storage Firmware Upgrade via TFTP, HTTP, TR-069 2-Level Administration Privilege Access Control Features: Access List, Brute Force Protection Syslog SMS, E-mail Notification Alert |
| Router Central Management Features | AP Management: Up to 20 VigorAP access points Switch Management: Up to 10 VigorSwitch network switches VPN Management: Up to 8 Vigor routers |
| Operating Requirements | Temperature Operating: 0°C to 45°C Humidity 10% to 90% non condensing Operating Power: DC 12V (via external PSU, supplied) |
User guides
Download User Guides:
Data Sheet
DrayTek Data Book
Quick Start Guide
Users Manual
Sonitus Home Ltd and Habitech New Build Showcase
Security Best Practice White Paper
