WyreStorm 4K60Hz HDBaseT 3.0 2 Gang UK Style In-Wall Transmitter and Receiver Kit: SET

WyreStorm's SWX-100-IW-UK is a HDBaseT 3.0 bundled set. This kit including a SW-130-TX-UK transmitter and RX3-100 receiver simplifies your setup with their all in one 4K60 4:4:4 HDBaseT 3.0 package and allows you to experience uncompressed 4K60 AV up to 100m. This set is perfect for installers and end users, with zero latency.

WyreStorm's SWX-100-IW-UK is a HDBaseT 3.0 bundled set. This kit including a SW-130-TX-UK transmitter and RX3-100 receiver simplifies your setup with their all in one 4K60 4:4:4 HDBaseT 3.0 package and allows you to experience uncompressed 4K60 AV up to 100m.

This set is perfect for installers and end users, with zero latency.

WyreStorm's SW-130-TX-UK transmitter features three inputs and powerful HDBaseT transmission, makes this powerful switching transmitter perfect for corporate meeting and classroom environments.

Automatic or manual switching of 2 HDMI's or USB-C and CEC power triggering via HDBaseT means a simple user experience. This sets the standard for in wall HDBaseT® transmission.

Further functionality allows USB devices to be routed back to the source via USB host, or natively via USB-C and charging for the connected USB-C device.

This sets the standard for in wall HDBaseT transmission can achieve 4K over 100m or 328ft and has the latest HDR standards, including HDR-10 and Dolby Vision at 30Hz.

WyreStorm's RX3-100 is an uncompressed 18G HDBaseT 3.0 receiver that achieves signal transmission up to 100m at 4K@60Hz via CAT6A cable. With HDBaseT 3.0, experience USB data transfers of up to 300Mbps, nearly doubling HDBaseT 2.0's capability of 190Mbps.

This heightened capacity supports high speed connections to 4K webcams, whiteboards and data drives.

Delivering uncompressed signal transmission, HDBaseT 3.0 offers the very latest in high speed transmissions with the increased bandwidth from 10Gbps to an outstanding 18Gbps over a dedicated category cable.

The main feature of the RX3-100 is the 3 device ports, which are capable of USB 2.0 pass through, which offers not only KVM functionality for extension of a keyboard, mouse or touchscreen, but also full data transfer capabilities of 300Mbps for 4K UHD webcams and high speed data drives.

This receiver offers both audio de-embed from the source HDMI and independent audio pass through lane from line in audio from the TX simultaneously.

Bi directional control and PoH is delivered by the RX-100. It boasts bidirectional PoH, which can power or be powered by a transmitters such as the SW-120-TX3-UK, while also passing bidirectional RS-232 control to either the display or back to the head end. If RS-232 isn't an option, it also supports CEC signals from the transmitter.

Specifications:

Features:

SW-130-TX-UK Transmitter

• Professional HDBaseT switcher/transmitter for video conference or meeting rooms
• 3 switchable inputs: 2 HDMI and USB-C supporting content up to 4K/30 4:4:4 and RGB or 4K/60 4:2:0 8 bit
• The latest HDR standards, including HDR-10 and Dolby Vision at 30Hz
• HDCP 2.2 encryption technology ensuring compatibility with the latest 4K UHD content and sources
• HD multichannel audio up to DTS:X and Dolby Atmos
• USB-C port supports alt-mode functionality for A/V and USB data
• USB-C charging for connected devices up to 2A
• Compatible with DVI-I and DP++ v1.3 signals from supported devices
• Additional 2 channel analogue audio input for sending separate stereo audio to RX
• USB2.0 host port for connection of far end devices such as webcams, smart touchscreens and microphones
• Automatic or manual CEC triggering for compatible connected screens or projectors
• Additional power input via DC port on rear via 12v 1A PSU which is not included
• Port shared with RS-232 input
• Control options include automatic switching, manual switching and CEC trigger and RS-232 control
• Compatible with TS-280 touchscreen for control with 12v power outlet
• 2 gang UK form factor, white fascia, non removable

RX3-100 Receiver

• HDBaseT 3.0 receiver supports uncompressed content up to 4K@60Hz 4:4:4 8bit, HDCP 2.3 encryption technology ensuring compatibility with the latest 4K UHD content and sources
• HD Multichannel audio up to DTS:X and Dolby Atmos via HDMI
• Compatible with DVI-I and DP++ v1.3 signals from compatible devices
• USB 2.0 pass through offering 300Mbps transfer and HID extension
• This receiver features 3x USB device ports
• Supports independent lane analogue audio pass through from transmitter to receiver
• Supports analog audio de-embed from HDMI
• Backwards compatible with HDBaseT 1.0 transmission and receiving devices, where the lowest denominator takes priority
• Bidirectional RS-232 and CEC passthrough communication
• Bidirectional PoH
