WyreStorm NetworkHD 500 Series 4K60 4:4:4 JPEG2000 Decoder

The WyreStorm Network HD NHD-500-RX is a decoder with HDMI 2.0 AV over IP solution, capable of encoding up to 4K 60 including Dolby Vision, HDR10 and HLG content. Offering the flexibility of Ethernet or fibre as a transport method, this ultra low latency encoder delivers incredibly fast matrix switching speeds.

The WyreStorm NetworkHD NHD-500-RX is a decoder with HDMI 2.0 AV over IP solution, capable of encoding up to 4K60 including Dolby Vision, HDR10 and HLG content.

Offering the flexibility of Ethernet or fibre as a transport method, this ultra low latency encoder delivers incredibly fast matrix switching speeds.

A powerful routing engine allows audio, video, USB and control signals to be discretely sent to any endpoint.

Create captivating video walls up to 16x16 in size and control them with the tap of a button in the amazing NetworkHD Touch control app.

The NHD-500-RX delivers major advances such as full HDMI 2.0 decoding, faster switching speeds, higher quality preview streams and fibre connectivity.

It is also capable of encoding full HDMI 2.0 content, including 4K60 4:4:4 8bit and high dynamic range video including Dolby Vision, HDR10 & HLG up to 12bit 4:2:2 at 60Hz over a 1GbE network.

Equipped with both Ethernet and fibre outputs, the 500 series offers flexibility for any installation. Ethernet can support transmissions up to 100m / 328ft and fibre is capable of a stunning 550m / 1800ft using OM3 MMF.

The encoder is fully compatible with the intuitive NetworkHD Touch control app for iPad and Android tablets. It offers effortlessly control matrix and video wall switching with high definition preview streams of each encoder's source. Control couldn't be easier with the free drag and drop intuitive interface.

Create captivating large format video walls with the ability to process up to 256 screens (16x16). Easily adjust for screen bezels to ensure the video is picture perfect. This encoder allows the creation of mosaic style walls with rotated screens.

Equipped with the latest security protocols including SSH, TLS and HTTPS, which means data and communications from the NHD-500-RX is encrypted end to end.

Ultra Low Latency and Power Routing is offered by less than a single frame a latency (16ms) when in passthrough mode allows content to be distributed without any perceivable delay.

All signals including audio, video, USB and control signal can be discretely routed and independently assigned between encoders and decoders.

Specifications:

Features:

• HDMI 2.0 decoding up to 4K60 4:4:4 8bit with Dolby Vision/HDR compatibility
• Flexible output supports either Ethernet or fibre connections (300m w/ OM3 fibre)
• USB connectivity for extension and routing of USB peripheral devices
• Ultra low latency transmissions of less than a single video frame
• NHD-500-RX decoder capable of 16x16 video wall processing, including mosaic
• High definition preview streams for control system interfaces
