Description
The Wyrestorm SW-515-RX is a powerful next generation HDBaseT receiver compatible with WyreStorm's presentation switcher platform. It is perfect for corporate meeting and classroom environments. It automatically switches between a remote source sent over HDBaseT® and 2 local HDMI sources, all with USB device extension.
The Wyrestorm SW-515-RX is a powerful next generation HDBaseT receiver compatible with WyreStorm's presentation switcher platform.
It is perfect for corporate meeting and classroom environments. It automatically switches between a remote source sent over HDBaseT® and 2 local HDMI sources, all with USB device extension. CEC triggering and 3rd party device relays further contribute to a superior and autonomous presentation experience.
HDBaseT® 2.0 affords the addition of USB 2.0 pass through, offering not only KVM functionality for extension of a keyboard, mouse or touchscreen but also full data transfer capabilities.
Additionally, it allows 2 host devices to be connected and the extender can route USB traffic depending on the currently selected source at the receiver.
Specifications:
| Audio and Video | |
| Inputs | 2 x HDMI: 19 pin type A 1 x HDBT In: 8 pin RJ45 female |
| Outputs | 1 x HDMI Out: 19 pin type A 1 x Audio Out: 3 pin Phoenix 1 x Line Out: 3.5mm TRS Stereo |
| Audio Formats | 2 channel analogue/PCM Multichannel: LPCM |
| Video Encoding | HDBaseT Class A |
| Encoding Data Rate | 9.2Gbps |
| End to End Latency | 10µs |
| Video Resolutions (Max) | 1920x1200p @60Hz 8bit HDMI: 15m/49ft CAT6: 150m/492ft CAT6a/7: 150m/492ft 1920x1080p @60Hz 8bit HDMI: 15m/49ft CAT6: 150m/492ft CAT6a/7: 150m/492ft 3840x2160p @30Hz 8bit 4:4:4 HDMI: 7m/23ft CAT6: 100m/328ft CAT6a/7: 100m/328ft 4096x2160p @60Hz 8bit 4:2:0 HDMI: 7m/23ft CAT6: 100m/328ft CAT6a/7: 100m/328ft |
| Maximum Pixel Clock | 297MHz |
| Communication and Control | |
| HDMI | HDMI HDCP 2.2 EDID DVI/D supported with adapter (not included) |
| HDBaseT™ | HDMI HDCP 2.2 EDID CEC 2 channel audio USB |
| Ethernet | 2 x 8 pin RJ 45 female Web UI IP Control Bidirectional over HDBaseT |
| RS-232 | 1 x RS-232 (control): 3 pin Phoenix 1 x RS-232 (passthrough): 3 pin Phoenix |
| IR | 1 x IR RX: 3.5mm TS mono |
| USB | 2 x USB Host: USB-B 3 x USB Device: USB-A USB over HDBT limited to 190Mbps Max 5v 500mA per USB Type A |
| Power Supply | 12V DC 2A |
| PoH | IEEE 802.3af 15.4W |
| Max Power Consumption | 16.25W |
| Operating Temperature | 0°C / 32°F to 45°C / 113°F |
| Storage Temperature | -20°C / -4°F to 70°C / 158°F |
| Maximum BTU | 555BTU/hr |
| Rack Units | <1U |
| Dimensions | Without feet/brackets/handles: Height: 42mm / 1.66" Width: 220mm / 8.67" Depth: 148.7mm / 5.86" |
| Weight | 0.97kg / 2.14lb |
| Regulatory: Safety and Emissions | CE, FCC, ROHS |
| Included | 1 x SW-515-RX receiver 1 x 12V DC power supply (US/UK/EU) 1 x IR transmitter, 2 x mounting brackets 4 x 3 pin screw down Phoenix connector 1 x 4 pin screw down Phoenix connector |
Features:
- HDBaseT receiver with switching inputs for education or corporate meeting rooms
- Automatic or manual switching between a remote HDBaseT source or 2 local HDMI's
- Bidirectional USB2.0 for connection of webcams, smart touchscreens and microphones
- Automatic or manual CEC triggering for compatible connected screens or projectors
- Condition based relays triggered on source presence
- Supports source content up to 4K/60 4:2:0 with HDCP 2.2
