Description
The WyreStorm SW-510-TX HDBaseT switcher brings the H2 and PRO products into one powerful meeting space solution. Supporting USB routing to both HDMI and DP inputs, the SW-510-TX accepts HDMI, DisplayPort and USB3.1c sources with a VGA+ audio input for legacy devices. It will support 4K content and even HDCP2.2 protected content.
The WyreStorm SW-510-TX HDBaseT switcher brings the H2 and PRO products into one powerful meeting space solution.
Supporting USB routing to both HDMI and DP inputs, the SW-510-TX accepts HDMI, DisplayPort and USB3.1c sources with a VGA+ audio input for legacy devices. It will support 4K content and even HDCP2.2 protected content.
When the meeting room is in idle state, the SW-510-TX can switch to either of its HDMI inputs which can be used for anything from a signage player to a satellite receiver, keeping the screen active and displaying content. These inputs can also be triggered manually at any time should a Chromecast or AppleTV be fitted for screen mirroring.
HDBaseT 2.0 affords the addition of USB 2.0 pass through, offering not only KVM functionality for extension of a keyboard, mouse or touchscreen but also full data transfer capabilities. Additionally, allowing 2 host devices to be connected, the extender can route USB traffic depending on the currently selected source at the receiver.
Specifications:
| Audio and Video | |
| Inputs | 1 x VGA In: 15 pin VGA 1 x Display Port In: Display Port 1.3 1 x HDMI In: 19 pin type A 1 x Audio In: 3.5mm TRS Stereo 1 x Line In: 3.5mm TRS Stereo |
| Outputs | 1x HDMI Out: 19 pin type A 1x HDBT Out: 8 pin RJ45 Female |
| Audio Formats | 2 channel analogue/PCM Multichannel: LPCM |
| Video Encoding | HDBaseT™ Class A |
| Encoding Data Rate | 9.2Gbps |
| End to End Latency | 10µs |
| Video Resolutions (Max) | 1920x1200p @60Hz HDMI: 8bit 15m/49ft CAT6: 150m/492ft CAT6a/7: 150m/492ft 1920x1080p @60Hz 8bit HDMI: 15m/49ft CAT6: 150m/492ft CAT6a/7: 150m/492ft 3840x2160p @30Hz 8bit 4:4:4 HDMI: 7m/23ft CAT6: 100m/328ft CAT6a/7: 100m/328ft 4096x2160p @60Hz 8bit 4:2:0 HDMI: 7m/23ft CAT6: 100m/328ft CAT6a/7: 100m/328ft |
| Maximum Pixel Clock | 297MHz |
| Communication and Control | |
| HDMI | HDMI HDCP 2.2 EDID DVI/D supported with adapter (not included) |
| HDBaseT | HDMI HDCP 2.2 EDID CEC 2 channel audio USB |
| Ethernet | 2 x 8 pin RJ45 female Bidirectional over HDBaseT |
| RS-232 | 1 x RS-232 (control): 3 pin Phoenix 1 x RS-232 (passthrough): 3 pin Phoenix |
| IR | 1 x IR RX: 3.5mm TS mono |
| USB | 1 x USB-C: USB 3.1 Audio/Video 2 x USB Host: USB-B 3 x USB Device: USB-A USB over HDBT limited to 190Mbps Max 5v 500mA per USB type A |
| Power Supply | 12V DC 3A |
| PoH | IEEE 802.3af 15.4W |
| Max Power Consumption | 14.02W |
| Operating Temperature | 0°C / 32°F to 45°C / 113°F |
| Storage Temperature | -20°C / -4°F to 70°C / 158°F |
| Maximum BTU | 56.3BTU/hr |
| Rack Units | <1U |
| Dimensions | Without Feet, Brackets or Handles: Height: 42mm / 1.66" Width: 220mm / 8.67" Depth: 148.7mm / 5.86" |
| Weight | 0.97kg / 2.14lb |
| Regulatory: Safety and Emissions | CE, FCC, ROHS |
| Included | 1 x SW-510-TX transmitter 1 x 12V DC power supply (US/UK/EU) 1 x IR receiver 2 x Mounting brackets 1 x 3 pin screw down Phoenix connector 1 x 4 pin screw down Phoenix connector |
Features:
- Professional switching transmitter for education or corporate meeting rooms
- Automatic or manual switching between HDMI, VGA, DisplayPort and USB C inputs
- Bidirectional USB2.0 for connection of webcams, smart touchscreens and microphones
- USB-C input supports Alt mode functionality for AV and USB device connection through a single cable
- Automatic or manual CEC triggering for compatible connected screens or projectors
- Supports source content up to 4K/60 4:2:0 with HDCP 2.2
