Description
Description:
Sonance's VX66R Thin Line 6" two way round in ceiling loudspeakers with brilliant white micro trim grilles are 3mm thinner than the legacy VP Thin Line series loudspeakers. They feature 1" tweeter with ceramic dome, Ferrofluid cooled and acoustic back chamber along with a 6.5" woofers with Kevlar / Nomex cone and rubber surround.
Sonance's Visual Experience Thin Line Series represents expert innovation of performance and design, delivering room filling sound from an elegantly slim profile. These architectural speakers combine advanced acoustic engineering that accommodates for challenging room architecture and space limitations; delivering Sonance VX into more applications, even in 2.5" metal framing for concrete construction.
The VX66R-TL Thin Line speakers accommodate for shallow construction and limited space. Available for in ceiling or in wall and selections for performance level and Single Stereo Technology, VX Thin Line models will complement the advanced performance of the standard Sonance VX Series models.
These speakers are engineered for maximum coverage and fidelity to create the most crisp and consistent experience possible.
Sonance's Sinusoidal Textured Waveguide provides the greatest dispersion possible so that everyone in the surrounding space receives the same experience, making it easier to design even and balanced audio systems.
The VX series range represent four decades of speaker design and innovation success to inspire and reimagine speaker technology for the future. These are Sonance's first loudspeakers to be engineered by an iterative combination of simulation, machine learning and expertly engineered for superior performance, finish, installation and most importantly, a great experience.
Features:
- Fits into 2.5" metal framing in concrete ceiling applications
- Higher performance, fidelity with the VX transducer technology
- VX waveguides provide consistent tonality and improved coverage
- 1" tweeter with ceramic dome, Ferrofluid cooled with an acoustic back chamber
- 6.5" woofer with a Kevlar / Nomex cone and rubber surround
- Sonance brilliant white VX Grilles
- 3mm thinner than ever, fits into more installations with small ceiling voids
- Array of grille options to ensure the best finish for your space
- VX Series is expertly engineered for superior performance, finish, installation and most importantly, a great experience
Specifications:
Frequency Response | 45Hz to 20kHz ±3dB |
Tweeter | 25mm / 1" ceramic dome, Ferrofluid-cooled, acoustic back chamber |
Woofer | 165mm / 6.5" Kevlar/Nomex cone, rubber surround |
Dispersion Technology | Sinusoidal textured waveguide |
Speaker Pivot | No Pivot |
Impedance | 8Ω nominal 6Ω minimum |
Recommended Power | 5W minimum 140W maximum |
Sensitivity | 90dB SPL (2.83V/1M) |
Mounting Technology | Flex Frame 1 stage, RotoLock® Clamp installation |
Standard Grille | Round Micro Trim Grille: 244.4mm / 9.62" |
Grille Options. Sold Separately | Round Trimless Grille: 235.6mm / 9.28" Square Micro Trim Grill: Height: 244.4mm / 9.62" Width: 244.4mm / 9.62" Square Trimless Grille: Height: 235.6mm / 9.28" Width: 235.6mm / 9.28" |
Speaker Mounting Depth | 74mm / 2.91" |
Mounting Depth + Retrofit Enclosure. Sold Separately | 132.4mm / 5.21" |
Cut Out Dimensions | 210mm / 8.25" |
Weight | 5.72kg / 12.61lb |
Quantity | Pair |
