Description
Christie's 3G-SDI Input Card is compatible with 4K7-HS and 4K10-HS projector models only. This card provides one low jitter SDI local loop out and supports SD-SDI, HD-SDI and 3G-SDI input signals with auto detection.
Christie's 3G-SDI Input Card is compatible with 4K7-HS and 4K10-HS projector models only.
This card provides one low jitter SDI local loop out and supports SD-SDI, HD-SDI and 3G-SDI input signals with auto detection.
The 3G-SDI-INPUT-CARD operates at bitrates of 2.970 Gbit/s, 2.970/1.001 Gbit/s, 1.485 Gbit/s, 1.485/1.001 Gbit/s and 270 Mb/s.
It extends the SDI input or output distance up to 100m for 3G-SDI, 200m for HD-SDI or 300m for SDSDI.
Please Note: This input card is not compatible with 4K22-HS model
Specifications:
Format | Pixel clock (MHz) | Frame rate (Hz) | Pixel Format | Bit Depth |
SD_720x480 | 13.5 | 30 | YCbCr 4:2:2 | 10 bit |
SD_720x576 | 13.5 | 25 | YCbCr 4:2:2 | 10 bit |
HD_1280X720 | 74.25 | 60 | YCbCr 4:2:2 | 10 bit |
HD_1920X1080 | 74.25 | 30 | YCbCr 4:2:2 | 10 bit |
HD_1280x720 | 74.25 | 50 | YCbCr 4:2:2 | 10 bit |
HD_1920x1080 | 74.25 | 25 | YCbCr 4:2:2 | 10 bit |
HD_1920x1080 | 74.25 | 30 | YCbCr 4:2:2 | 10 bit |
HD_1920x1080 | 74.25 | 25 | YCbCr 4:2:2 | 10 bit |
HD_1920x1080 | 74.25 | 24 | YCbCr 4:2:2 | 10 bit |
HD_1920x1080 | 74.25 | 30 | YCbCr 4:2:2 | 10 bit |
HD_1280x720 | 74.25 | 60 | YCbCr 4:2:2 | 10 bit |
HD_1920x1080 | 74.25 | 24 | YCbCr 4:2:2 | 10 bit |
HD_1920x1080 | 74.25 | 30 | YCbCr 4:2:2 | 10 bit |
3GA_1920x1080 | 148.5 | 50 | YCbCr 4:2:2 | 10 bit |
3GA_1920x1080 | 148.5 | 60 | YCbCr 4:2:2 | 10 bit |
3GA_1920x1080 | 148.5 | 60 | YCbCr 4:2:2 | 10 bit |
3GA_1920x1080 | 148.5 | 25 | YCbCr 4:2:2 | 10 bit |
3GA_1920x1080 | 148.5 | 30 | YCbCr 4:2:2 | 10 bit |
3GA_1920x1080 | 148.5 | 30 | YCbCr 4:2:2 | 10 bit |
3GA_1920x1080 | 148.5 | 25 | YCbCr 4:2:2 | 10 bit |
3GA_1920x1080 | 148.5 | 30 | YCbCr 4:2:2 | 10 bit |
3GB_1920x1080 | 148.5 | 30 | YCbCr 4:2:2 | 10 bit |
PSF_1920x1080 | 74.25 | 30 | YCbCr 4:2:2 | 10 bit |
PSF_1920x1080 | 74.25 | 30 | YCbCr 4:2:2 | 10 bit |
PSF_1920x1080 | 74.25 | 25 | YCbCr 4:2:2 | 10 bit |
Features:
- Provides one low jitter SDI local loop out
- Supports SD-SDI, HD-SDI and 3G-SDI input signals with auto detection
- Operates at bitrates of 2.970 Gbit/s, 2.970/1.001 Gbit/s, 1.485 Gbit/s, 1.485/1.001 Gbit/s and 270 Mb/s
- Extends SDI input/output distance up to 100m for 3G-SDI, 200m for HD-SDI or 300m for SDSDI
Please Note: This input card is not compatible with 4K22-HS model
