Description
Description:
The VigorSwitch G2100 works superbly in standalone mode and is also designed for centralised management. It can be provisioned and monitored by one of DrayTek's central management platforms. These include the VigorACS management platform, VigorConnect onsite management and DrayTek's router based switch management. These platforms allow for a drastic reduction in the setup time for a complex network and for configuring an entire DrayTek network remotely.
Features:
- Eight RJ-45 Gigabit Ethernet ports
- Cloud managed with VigorACS
- 802.1q VLANs with dynamic MAC based, voice and surveillance VLAN
- ONVIF IP camera surveillance management with device check
- Access Control List (ACL) for port and traffic level security
- Port mirroring and link aggregation
- IGMP snooping and querying
- IPv4 and IPv6 support with IP conflict prevention
- Centrally managed or standalone operation
Specifications:
| Physical Interfaces | 8 RJ-45 Ethernet ports - 10/100/1000Mbps |
| 2 SFP Ports | 1000Mbps |
| VLAN Support | Yes |
| QoS Support | 8 queues Queue scheduling SPQ and WRR Class of Service: 802.1p CoS, DSCP, CoS-DSCP and IP Precedence |
| Network Security | Yes |
| Spanning Tree Support | Yes |
| Link Aggregation | Yes. Up to 8 groups |
| Switching Capacity | 20Gbps |
| Multicast Support | Yes Up to 256 groups |
| IGMP v2 or v3 Support | Yes Both snooping and querier |
| Authentication, Authorisation, Accounting (AAA) Support | Yes |
| ONVIF Surveillance Management | Discovery of ONVIF compliant IP cameras and stream preview |
| Management | Central Management VigorACS VigorConnect Vigor Router Switch Management |
| L3 Networking Features | Static Route VLAN Routing DHCP Server |
| Power Supply | Internal with maximum input power c consumption of 18W |
| Cooling | Passively cooled |
| Environmental | 0°C / 32°F to 50°C / 122°F Relative Humidity: 5% to 90% non condensing |
| Rack Space | 1U |
| Dimensions | Height: 44mm / 1.73" Width: 319mm / 12.56" Depth: 208mm / 8.19" |
| Weight | 2.61kg / 5.75lb |
| Application | Rack mountable |
User guides
Download User Guides:
Data Sheet
DrayTek Data Book
User Guide
Security Best Practice White Paper
