Description
The Christie's 4K-HS high performance UHD 1DLP laser projectors combine the cost savings of 1DLP® technology, the long operational life of laser and the image quality of 4K UHD resolution. The result is a trio of high performance 7600, 14,800 and 22,500 ISO or 7000, 12.500 and 19,000 ANSI lumen, 4K UHD, HDR10 compatible laser projectors that won't blow your budget.
Please select your required projector brightness and appropriate lens.
This CHR-4K-HS projector outperforms the competition due to the enhanced colour performance delivered by Christie's BoldColor Technology. Colours are vibrant and natural and with the added fidelity of 4K UHD resolution, so visuals simply pop off the screen.
These projectors features built in Christie Twist???™ for fast and easy multi projector setups. For even more flexibility they has two expandable option card slots which can accommodate cards such as the Christie Terra input card, 3G SDI input cards and HDBaseT input cards. Plus, with HDMI 2.0, Display Port 1.2 Inputs, you can feed the projector 4K60Hz content over a single HDMI or Display Port cable for simplified setup and cable routing
The laser light source offers a dynamic contrast ratio of 5000:1 and offers 20,000 hours performance to 50% brightness, allowing for consistent viewing.
There's a huge range of optional lenses, from the innovative 0.38:1 fixed UST to a choice of zoom lenses from 0.85 to 1.02:1 right up up to 5.66 to 10.18:1 with full ILS.
Fully compatible with the Christie One Mount Plus system of ceiling mounts, which offer a high degree of tilt and roll, plus fine tune fingertip controls for precise tool free and easy adjustments.
Specifications:
CHR-4K-HS-22 | CHR-4K-HS-13 | CHR-4K-HS-7 | |
Image Brightness | 22,500 ISO 19,000 ANSI |
14,800 ISO 12,500 ANSI |
7600 ISO 7000 ANSI |
Type | 1 x 0.95" DMD | 1 x 0.95" DMD | 1 x 0.66" DMD |
Native Resolution | 4K UHD (8.3MP) 3840 x 2160 16:9 |
4K UHD (8.3MP) 3840 x 2160 16:9 |
4K UHD (8.3MP) 2716 x 1528 (WQXGA+) DMD (native) 16:9 |
Illumination Type | Laser phosphor with Christie BoldColor Technology | Laser phosphor with Christie BoldColor Technology | Laser phosphor with Christie BoldColor Technology |
Performance | 20,000 hrs to 50% brightness | 20,000 hrs to 50% brightness | 20,000 hrs to 50% brightness |
Inputs | HDMI x 2 (HDCP 2.2 Compliant) DisplayPort x 1 (version 1.2) 12G-SDI x 1 (BNC) USB x 1 (Type A RS-232 in Control via HDBaseT Ethernet (10/100) RJ45 |
HDMI x 2 (HDCP 2.2 Compliant) DisplayPort x 1 (version 1.2) 12G-SDI x 1 (BNC) USB x 1 (Type A) RS-232 in Control via HDBaseT Ethernet (10/100) RJ45 |
HDMI x 2 (HDCP 2.2 Compliant) DisplayPort x 1 (version 1.2) DVI-D x 1 (digital only) USB x 1 (Type A) RS-232 in |
Signals | 4096 x 2160/3840x2160 @ 60Hz | 4096 x 2160/3840x2160 @ 60Hz | 4096 x 2160/3840x2160 @ 60Hz |
Power Consumption | Normal power consumption: 1553W Eco1 mode (80%): 1281W Eco2 mode (50%) 806W |
Normal power consumption: 1030W Eco1 mode (80%): 854W Eco2 mode (50%) 545W |
Maximum power consumption: 1250W Eco1 mode (80%): 1010W Eco2 mode (50%): 630W |
Dissipation | Normal mode: 5295 BTU/hr Eco1 mode: 4368 BTU/hr Eco2 mode: 2748 BTU/hr |
Normal mode: 3512 BTU/hr Eco1 mode: 2912 BTU/hr Eco2 mode: 1858 BTU/hr |
Normal mode: 2900 BTU/hr Eco1 mode: 2388 BTU/hr Eco2 mode: 1587 BTU/hr |
Dimensions | Without Feet: Height: 203mm / 7.99" Width: 596mm / 23.46" Length: 677mm / 26.65" |
Without Feet: Height: 203mm / 7.99" Width: 596mm / 23.46" Length: 677mm / 26.65" |
Without Feet: Height: 214mm / 8.4" Width: 520mm / 20.5" Length: 600mm / 23.6 |
Weight | 43.5kg / 95.9lb | 43.5kg / 95.9lb | 34kg / 74.96lb |
Features:
- Benefits from high fidelity visuals at an affordable price with 1DLP 4K UHD resolution
- Laser ?illumination combined with Christie's BoldColor Technology for the highest quality images, life like visuals and reliability
- Long life laser light source with up to 20,000 hours to 50% brightness of virtually maintenance free operation
- Small form factor and weighs less than 96lb for easy shipping, lifting and installation
- Compatible with Christie Twist? for quicker and easier multi projector setups
- Fully omnidirectional with unrestricted design and installation flexibility
- Customisable with two expandable option card slots
- Full and comprehensive connectivity for popular formats including 3GSDI (optional) for added redundancies
- With advanced electronics, firmware updates take only minutes
- DICOM simulation mode for advanced grayscale image reproduction, perfect for analysing xrays and medical scans for training purposes
- TAA compliant
