RTI VXP-82 8x2 All In One Control Processor and AV Presentation Switcher

Description:

RTI's VXP-82 8x2 all in one control processor and AV presentation switcher combines a robust control processor with a built in Audio/Video presentation switcher to deliver a single box solution for conference rooms, classrooms and lecture halls.

The VXP-82 enables control from RTI touch panels, keypads, remote controls or mobile apps, while its 8x2 switcher distributes Audio/Video signals over HDMI® and HDBaseT™ simultaneously to one or two rooms.

Existing in room USB web conferencing cameras, microphones and speakers can be connected and switched as well as traditional analogue or digital audio and video sources such as computers or laptops, document cameras, media servers and streamers, DVD players and microphones.

The VXP-82 is ideal for BYOD settings and social distancing office configurations. KVM control over USB allows for multiple presentation control options using USB keyboard and mouse from different spots in the same or secondary room.

Additional features include a 4K video scaler and an audio mixer.

Features:

• 8x2 4K All in one Control Processor or Scaling Presentation Matrix Switcher
• Support for HDCP 2.2 and HDMI 2.0
• Built in scaler supports up to 4K@60Hz 4:4:4 8bit video output
• HDBaseT inputs/output using VXP-R/VXP-T PoE extenders, available separately
• Supports de-embedded audio of HDMI and HDBaseT outputs, set independently to output any mixed result
• Eight video inputs mixed format
• Two video outputs HDMI and HDBaseT
• Control via front panel, built in processor and Web UI
• RS-232: Two control port for 3 wire connection with the capability of polling status feedback from controlled devices or systems
• Relay: Three built in low voltage dry contacts that provide contact closure or switching control
• IR Control Ports: Six multi purpose Input/Output control port that allows for infrared control with IR emitters, blasters and repeaters connecting voltage sensors or RS-232 communicating modules
• Three Voltage Trigger
• Three Voltage Sense Inputs
• Ethernet: Standard 10/100 BaseT network connection for bidirectional control communication with RTI remotes, touch panels and devices that are controlled over IP network
• Built in astronomical clock that syncs through an internet connection allows to schedule time based events to automate all aspects of the installed environment, including climate, lighting, music and much more
• Allows for mounting the unit into a standard 19" wide rack (2U) or placing on any surface using the included feet

Specifications:
