Description:
Designed for centralised management, the VigorSwitch G1282 can be provisioned and monitored with the VigorACS management platform, the free VigorConnect single site management system and/or, with a DrayTek Vigor router's Central Switch Management.
Easily provision VLAN configuration through the router and clone switch configurations. Drastically reduce the setup time required for a complex network and configure an entire DrayTek network remotely.
Features:
Specifications:
Physical Interfaces | 24 x 10/100/1000BaseT Ethernet Ports (RJ-45 IEEE 802.3/3u/ab) 4 Selectable Ports (Nos. 25-28), use as either: 10/100/1000BaseT (Gigabit) Ethernet or SFP (802.3z) |
VLAN | 802.1q VLAN Tag-based VLAN Port-based VLAN Up to 4K VLANs (out of 4096 VLAN IDs) Protected Port Voice VLAN (OUI Mode) Management VLAN |
Quality of Service | Support 8 priority queues Port-Based rate control Priority queue schedule (WRR or Strict Priority) Class of Service |
Network Security | Access Control Lists (ACL) Source and destination MAC VLAN ID IPv4/v6 address |
Supported Protocols | Storm Control (Broadcast, Unknown Multicast, Unknown Unicast) DoS Attack protection AAA Authentication |
Link Aggregation | Combine multiple ports to increase bandwidth 8 Aggregation Groups Up to 8 ports in each group LCAP or Static setup Supports traffic load balancing |
Networking Performance | Switching Capacity: 56Gbps Forwarding Rate: 41.7Mpps MAC Addresses Supported: 8K Jumbo Frames up to 9KB |
IGMP Snooping | Up to 256 multicast groups IGMP Snooping V2/V3 (BISS) IGMP V2/V3 Querier Immediate Leave |
Power | Power Input Requirements: 220 to 240VAC Internal Maximum Input Power Consumption: 36W |
Operating Requirements | Operating Temperature: 0 °C to 50 °C Storage Temperature: -20 °C to 70 °C Operating Humidity: 10% to 90% RH non condensing |
Rack Space | 1U |
Dimensions | Height: 44mm / 1.73" Width: 441mm / 17.36" Depth: 206mm / 8.11" |
Weight | 2.8kg / 6.17lb excluding SFP modules or cables |
Application | Rack mountable |
Included | Brackets included for rack or wall mounting |
